Vehicles model |
JDF5100GYYE型運油車 |
Proclamation |
217 |
|
Production enterprise |
湖北江南專用特種汽車有限公司 |
Brand |
江特牌 |
|
Overall dimensions(mm) |
7100×2400×3100 |
GVW(Kg) |
10400 |
|
Body internal dimensions(mm) |
×× |
Rated loading capacity(Kg) |
5400 |
|
Approach/departure angle |
26/16 |
Mass in working order(Kg) |
4805 |
|
F/R suspension(mm) |
1065/2085 |
Max speed(km/h) |
85 |
|
Vehicle Identification code |
LGAW1A12×××××××××
LGAW1B12××××××××× |
|
|
|
Chassis model |
EQ1102FD3GJ |
|
|
|
Engine type |
Producer |
Exhaust/hp |
Hp |
|
YC4E140-31
YC4E140-30
YC6J160-31
YC4E140-33
EQH140 30
ISF3.8s3141 |
廣西玉柴機器股份有限公司
廣西玉柴機器股份有限公司
廣西玉柴機器股份有限公司
廣西玉柴機器股份有限公司
東風汽車有限公司商用車發動機廠
北京福田康明斯發動機有限公司 |
4260
4260
6500
4260
4752
3760 |
103
105
118
105
103
105 |
|
燃料種類 |
Diesel |
The performance is standard |
GB3847-2005,GB17691-2005國Ⅲ |
|
Number of axles |
2 |
Number of tire |
6 |
|
Wheel base |
3950 |
Tire specification |
9.00-20 |
|
Axis Holland |
3990/6410 |
F track base |
1810 |
|
Number of Spring |
9/11+8 |
R track base |
1800 |
|
其它 |
運輸介質:Gasoline;密度:700千克/立方米;罐體有效容積:8.1方米;罐體Overall dimensions(長×長軸×短軸)(mm):4000×2100×1440;僅采用YC4E140-33發動機. |
|
|
